Key Details & Specifications

• Primary Application: Commonly utilized on FAW J5P and FAW J6 commercial trucks and dump trucks. It is also found on select Yuchai industrial applications.

• Engine Compatibility: Specifically engineered to fit FAW Xichai (Wuxi Diesel) engines, including the CA6110, CA6DF1, CA6DL2, and CA6DM2 series heavy-duty diesel engines.

• Electrical & Mechanical Specs:

• Voltage: 24-Volt electrical system

• Power Output: Rated at 4.5 KW to 5.5 KW depending on production series

• Drive Gear: 12-tooth (12T) pinion gear

• Rotation: Clockwise (CW) rotation

• OEM & Factory Designations: This component corresponds to factory starter model family QDJ276 / QDJ276A and is sometimes stamped under cross-reference variation 3708010-29DB or 3708010-29DJ.
