Key Details & Specifications

• Primary Application: Widely used in CAMC (Hualing / Hanma) heavy-duty trucks and dump trucks.

• Engine Compatibility: Specifically engineered to fit Weichai (such as WP10H) and CAMC CM6D18 series large-displacement diesel engines.

• Electrical Specifications: Operates on a standard 24-Volt commercial truck electrical system. It is a powerful 8.0 KW (or 7.5 KW depending on factory trim) unit featuring an 11-tooth (11T) drive pinion gear with clockwise (CW) rotation.

• Cross-Reference Numbers: This assembly directly interchanges with part numbers N-24000-0011 (or N240000011), Krauf numbers STB1809MH and STQ1809LP, and factory model designation QD2845E.
